Yaskawa YASNAC PC NC I/O Signal Function Manual User Manual
Yasnac pc nc i/o signal function manual
Table of contents
Document Outline
- 1
- 1.1 F-1 Digit Selection Signal 1-2
- 1.2 No. 2 G00 Mode Signal 1-3
- 1.3 Feed Completed Output Signal 1-4
- 1.4 Feed Override Input and Feedrate Override Cancel Input Signals 1-5
- 1.5 Pulse Handle Axis Selection Signals 1-7
- 1.6 Rapid Traverse Override Input Signal 1-8
- 1.7 Manual Feed Axis/Direction Selection Input Signal 1-9
- 1.8 Solid Tap 1-10
- 1.1 F-1 Digit Selection Signal
- 1. If the F1 digit feed function is selected, it is not possible to designate feedrates of 1mm/mi...
- 2. If the dry run switch is ON, the feedrate set for dry run operation is valid.
- 3. The feed override function is invalid when the F-1 digit feed function is used.
- 4. Feedrates set for setting parameters pm0820 to pm0828 remain valid even if the power is turned...
- 5. Feedrates called by the designation F1 digit codes are clamped in the following manner:
- 1.2 No. 2 G00 Mode Signal
- 1.2.1 No. 2 G00 Mode Input Signals (#31019 to #31014)
- 1.2.2 No. 2 G00 Mode Input Signals (#36280 to 36284)
- 1.3 Feed Completed Output Signal
- 1.4 Feed Override Input and Feedrate Override Cancel Input Signals
- 1.5 Pulse Handle Axis Selection Signals
- 1.6 Rapid Traverse Override Input Signal
- 1.7 Manual Feed Axis/Direction Selection Input Signal
- 1.8 Solid Tap
- 1.1 F-1 Digit Selection Signal
- 3.1 Calendar Output Signal
- 4
- M, S, T And B Functions
- 4.1 Input/Output Signals of M,S,T and B Codes
- 4.2 S5-Digit Command Input Signal
- S Code Analog Output Inverse Input
- SINV
- #31104
- S Code Analog Output Status Output
- SINVA
- #36500
- Spindle Gear Range Input
- GR1 to GR4
- #31100 to #31103
- pm1404
- Max. spindle speed when “GR1” input is “closed”
- Ö
- pm1405
- Max. spindle speed when “GR2” input is “closed”
- Ü
- pm1406
- Max. spindle speed when “GR3” input is “closed”
- á
- pm1407
- Max. spindle speed when “GR4” input is “closed”
- à
- pm1400
- Max. spindle speed when “GR1” input is “closed”
- Å
- pm1401
- Max. spindle speed when “GR2” input is “closed”
- Ç
- pm1402
- Max. spindle speed when “GR3” input is “closed”
- É
- pm1403
- Max. spindle speed when “GR4” input is “closed”
- Ñ
- 4.3 Gear Range Selection Input and Output Signals
- Gear Range Selection Command Output
- GR1S to GR4S
- #36504 to #36507
- S Function Finish Input
- SFIN
- #31117
- Gear Shift Input Signal
- GRO
- #31107
- Spindle Fixed Speed Input Signal
- SOR
- #31106
- 0
- 0
- Voltage corresponding spindle speed specified in CNC program
- 0
- 1
- Voltage set for parameter pm1412
- 1
- 0
- Voltage set for parameter pm1413
- 1
- 1
- Voltage set for parameter pm1413, 0 V
- Spindle Speed Agreed Input Signal
- SAGR
- #31116
- Spindle Speed Override Input Signal
- SPA to SPE
- #31110 to #31114
- 1
- 1
- 1
- 50%
- 0
- 1
- 1
- 60%
- 0
- 1
- 0
- 70%
- 1
- 1
- 0
- 80%
- 1
- 0
- 0
- 90%
- 0
- 0
- 0
- 100%
- 0
- 0
- 1
- 110%
- 1
- 0
- 1
- 120%
- 0
- 0
- 0
- 1
- 0
- 10%
- 0
- 0
- 1
- 1
- 0
- 20%
- 0
- 1
- 1
- 1
- 0
- 30%
- 1
- 1
- 1
- 1
- 0
- 40%
- 1
- 1
- 1
- 0
- 0
- 50%
- 0
- 1
- 1
- 0
- 0
- 60%
- 0
- 1
- 0
- 0
- 0
- 70%
- 1
- 1
- 0
- 0
- 0
- 80%
- 1
- 0
- 0
- 0
- 0
- 90%
- 0
- 0
- 0
- 0
- 0
- 100%
- 0
- 0
- 1
- 0
- 0
- 110%
- 1
- 0
- 1
- 0
- 0
- 120%
- 1
- 0
- 1
- 1
- 0
- 130%
- 1
- 0
- 0
- 1
- 0
- 140%
- 1
- 0
- 0
- 1
- 0
- 150%
- 0
- 1
- 0
- 1
- 0
- 160%
- 0
- 1
- 0
- 1
- 1
- 170%
- 0
- 1
- 0
- 0
- 1
- 180%
- 0
- 0
- 0
- 0
- 1
- 190%
- 1
- 0
- 0
- 0
- 1
- 200%
- Binary S Command Input Signals
- SDI0 to SD123
- #36540 to #36567
- 10
