12 Technical Data SMA Solar Technology AG
50 TCS-JP-IA-en-10 Installation Manual
12.3 Transformer Compact Station 800SC-JP
Electrical Data
Suitable for inverter type
SC 800CP-10-JP
Rated power at 25°C 880 kVA
Nominal power at 40°C 800 kVA
Nominal voltage 6,600 V
Configurable grid voltages 6,150 V / 6,300 V / 6,450 V / 6,600 V / 6,750 V
Maximum output current 77 A
Power frequency 50 Hz or 60 Hz
Nominal input voltage 360 V
Maximum input current 1,411 A
Transformer vector group Dy11
Dimensions and Weight
Width x height x depth
1,700 mm x 2,440 mm x 2,360 mm
Weight ∼ 8.5 t
Ambient Conditions
Ambient temperature
− 20°C to 40°C
Maximum relative humidity 15% to 85%
Maximum operating altitude above MSL 1,000 m
Degree of protection IP23D
Wind and snow loads in accordance with Japanese Building Code, JEM, JIS
Seismic requirements in accordance with JSIA - N0005 2011.04.01
seismic class A
Color
Enclosure wall
5Y7/1 (similar to RAL 7032)
