1 Information on this Document
1.1 Validity
This document is valid for the following device types:
• TCS-500SC-JP (Transformer Compact Station 500SC-JP)
• TCS-630SC-JP (Transformer Compact Station 630SC-P)
• TCS-800SC-JP (Transformer Compact Station 800SC-JP)
1.2 Target Group
This document is intended for qualified persons. The tasks described in this document must be performed by qualified
persons only. Qualified persons must have the following skills:
• Knowledge of how inverters work and are operated
• Training in how to deal with the dangers and risks associated with installing and using electrical devices and
installations
• Training in the installation and commissioning of electrical devices and installations
• Knowledge of all applicable standards and directives
• Knowledge of and compliance with this document, including all safety information
1.3 Additional Information
Links to additional information can be found at www.SMA-Solar.com:
1.4 Symbols
1.5 Nomenclature
Title Document type
Installation Requirements for Various Station Concepts of the
Transformer Compact Stations 500SC-JP/630SC-JP/800SC-JP
Technical Information
Symbol Explanation
'$1*(5
Indicates a hazardous situation which, if not avoided, will result in death or serious injury
:$51,1*
Indicates a hazardous situation which, if not avoided, can result in death or serious injury
&$87,21
Indicates a hazardous situation which, if not avoided, can result in minor or moderate injury
/05*$&
Indicates a situation which, if not avoided, can result in property damage
Information that is important for a specific topic or goal, but is not safety-relevant
☐ Indicates a requirement for meeting a specific goal
☑ Desired result
✖ A problem that might occur
Complete designation Designation in this document
Transformer Compact Stations 500SC-JP/630SC-JP/800SC-JP Transformer Compact Station
Sunny Central CP-JP Sunny Central or inverter
