10 Maintenance SMA Solar Technology AG
42 TCS-JP-IA-en-10 Installation Manual
10.2 Maintenance Schedule
10.2.1 Notes on the Maintenance Work
Compliance with the specified maintenance intervals will ensure trouble-free operation of the
Transformer Compact Station.
Maintenance work on the high-voltage transformer must be performed according to the documentation of the
high-voltage transformer.
10.2.2 Monthly Maintenance Work
10.2.3 Maintenance Work Every 6 Months
10.3 General Maintenance
10.3.1 Optical Inspection
1. Check the Transformer Compact Station for visual defects such as discoloration, dirt, damage and scratches on the
enclosure. If visual defects are present, repair these immediately.
2. Make sure that the protective covers are in place and undamaged. Clean soiled protective covers and eliminate any
defects immediately.
3. Ensure that there are no objects on or in the Transformer Compact Station that are flammable or that could otherwise
endanger the operational safety of the Transformer Compact Station.
4. Make sure that the enclosure openings are protected from penetration by foreign bodies (e.g., animals or leaves).
If the enclosure openings are not adequately sealed, renew the sealing material.
Adverse ambient conditions
Location and ambient conditions influence the maintenance intervals. In particular, cleaning and corrosion protection
work may be required more frequently depending on the conditions at the installation site.
• If the PV power plant is subject to adverse ambient conditions, it is recommended to shorten the maintenance
intervals.
Consumables and maintenance materials
This document only lists those consumables and maintenance materials that are not part of the standard equipment
of an electrically qualified person. Standard tools and materials such as torque wrenches, voltage detectors and
wrenches are required equipment for all maintenance operations.
Task See
Optical Inspection Section 10.3.1, page 42
Checking the Latches, Door Stops and Hinges Section 10.3.2, page 43
Checking the Transformer Compact Station for Corrosion Section 10.3.4, page 44
Checking the Fans Section 10.3.5, page 44
Task See
Cleaning the Interior Section 10.3.6, page 45
Checking the Seals Section 10.3.7, page 45
Checking the Bolted Connections of the Power Cabling Section 10.4.1, page 46
Checking the Bolted Connections on the Transformer Compact Station Section 10.4.2, page 47
