SMA STP 60-US-10 Installation User Manual
Page 64
1 Einführung
SMA Solar Technology AG
64
STP60-10-IA-xx-10
Installationsanleitung
Abbildung 1.5 Überblick über den Installationsbereich
Tabelle 1.2 Überblick über den Installationsbereich
PELV (berührungssicher)
2
Geräteerdung
7
Ethernet-Schnittstelle x 2
8
RS-485-Schnittstelle (nicht im Einsatz)
Spannungsführende Teile
1
AC-Anschlussklemmen
5
PV-Anschlussklemmen
Sonstiges
3
AC-Überspannungsschutz (SPDs)
4
DC-Überspannungsschutz (SPDs)
6
PV-Lasttrennschalter
