NV5128 Multi-Format Router • User’s Guide 83
7. Technical Details
Chapter 7 provides electrical, video, audio, and mechanical specifications for the NV5128. It dis-
cusses these topics:
• Power Specifications (Internal, PS6000)
• Physical Specifications
• Environmental Specifications
• Audio Specifications
• Video Specifications
• Time Code Specifications
• Machine Control Specifications
Power Specifications (Internal, PS6000)
The following table provides power specifications for the NV5128 Multi-Format Router’s internal
power supplies (PS6000):
Specification Details
AC input 90 – 130 or 180 – 250 VAC, 50/60 Hz, Auto-ranging
AC fuses Power Supplies:
8A (part number HB0145-00), slow-blow; 90
– 130 V
6.3A (part number HB0031-00), slow-blow, 180 – 250 V
AC connectors 2, IEC 320
AC power PS6000, 660 Watts, one IEC 320
AC power usage Note: Power is based on PS6000 modules and power consumption
dependent on number of cards installed.
425 Watts nominal (128×128 SD), power factor corrected.
550 Watts nominal (128×128 SWB), power factor corrected.
260 Watts nominal (128×128 Analog Video), power factor corrected.
500 Watts nominal (128×128 AVC), power factor corrected.
225 Watts nominal (128×128 Sync AES), power factor corrected
625 Watts nominal (128×128 Analog Audio), power factor corrected.
Regulatory UL listed and CE compliant
