KAM-XM-SERIES Instruction Manual 73
Specifications
Specifications
Table 6. KAM-XM Series Specifications
Parameter Value
SD/HD Video Input
Standard
KAM-XM-UNC
KAM-XM-UPC
SMPTE 259-C (270 Mb/s)
KAM-XM-UDC SMPTE 259-C (270 Mb/s), SMPTE 292M (1.5 Gb/s), SMPTE 274M, SMPTE 296M,
SMPTE 349M
KAM-XM-DNC SMPTE 292M (1.5 Gb/s), SMPTE 274M, SMPTE 296M, SMPTE 349M
Number of inputs 1 with active loop-through
Connector BNC per IEC 60169-8 Amendment 2
Equalization
KAM-XM-UNC
KAM-XM-UPC
Automatic to 300 m @ 270 Mb/s with Belden 1694 or equivalent cable
KAM-XM-UDC Automatic to 100 m @ 1.5 Gb/s/300 m @ 270 Mb/s with Belden 1694 or equivalent
KAM-XM-DNC Automatic to 100 m @ 1.5 Gb/s with Belden 1694 or equivalent cable
Return Loss > 15 dB @ 270 Mb/s (and 1.5 Gb/s)
Active Input Loop-through Output
Standard
KAM-XM-UNC
KAM-XM-UPC
SMPTE 259-C (270 Mb/s)
KAM-XM-UDC
SMPTE 259-C (270 Mb/s), SMPTE 292M (1.5 Gb/s), SMPTE 274M, SMPTE 296M,
SMPTE 349M
KAM-XM-DNC SMPTE 292M (1.5 Gb/s), SMPTE 274M, SMPTE 296M, SMPTE 349M
Number of outputs 1
Connector BNC per IEC 60169-8 Amendment 2
DC offset 0 V ± 0.5 V
Rise and fall time 750 ps nominal for SD
Overshoot < 10% of amplitude
Return loss > 9 dB @ 1.5 Gb/s
Wideband jitter < 0.2 UI
Up/Down Converted Serial Video Output
Standard
KAM-XM-UNC
KAM-XM-UPC
KAM-XM-DNC
SMPTE 292M (1.5 Gb/s)
KAM-XM-UDC SMPTE 259-C (270 Mb/s) or SMPTE 292M (1.5 Gb/s)
Number of outputs 2
Connector BNC per IEC 60169-8 Amendment 2
DC offset 0 V ± 0.5 V
Rise and fall time 750 ps nominal for SD
Overshoot < 10% of amplitude
Return loss > 15 dB @ 270 Mb/s, > 9 dB @ 1.5 Gb/s
