Introduction
This manual covers installation, configuration and operation of the fol-
lowing Kameleon KAM-XM Series modules:
•
KAM-XM-UDC – HDTV Up/Down Converter
•
KAM-XM-UPC – HDTV High Quality Up Converter
•
KAM-XM-UNC – HDTV Up Converter with Advanced SDTV Noise
Reduction
•
KAM-XM-DNC – HDTV Down Converter
Module functionality is summarized in
.
Table 1. KAM-XM Up and Down Converter Module Summary
Function
KM-XM-UDC
KM-XM-UPC
KM-XM-UNC
KM-XM-DNC
Aspect Ratio Control
X
X
X
X
Proc Amp Adjustments (for video processing)
X
X
X
X
Color Space Conversion
X
X
X
X
Detail Enhancement
X
X
X
X
Spike Filter (Adaptive Median filtering)
X
Brickwall Filter
X
Temporal Recursive Filter (Auto or Manual mode)
X
GPI Control (3 external GPI inputs controlling E-MEMs)
X
X
X
X
Color Legalizer Control
X
X
X
X
First 2 audio groups of HD video are re-embedded into SDI
stream
X
X
First 2 audio groups of SDTV video re-embedded into HD out-
put stream with compensating delay.
X
X
X
Re-insertion of Closed Caption data into HD output stream
X
X
X
