50 Jupiter AccuSwitch Soft Panels and Status Display Instruction Manual
Section 4 — VSD Introduction
Grid Colors : Provides a way to change how the following will be dis-
played: Source Text color, Destination Text color, Selection background,
Locked Text color, and Protected Text color. Clicking the
Edit button for any
of the above mentioned options will open the Color dialog.
Buttons
Restore All Defaults button : Provides a way to return to the original
display options.
OK button : Provides a way to save and apply changes, then closes the
Options window.
Cancel button : Provides a way to close the Options window without
saving changes.
Use of Color
The VSD uses color to indicate the following functionality:
The VSD will also show the CM status using the following colors:
Table 6. Colors and Functionality
Button Color Function
Green Sources
Yellow Destinations
Red Lock status
Magenta Protect status
Blue Pathfinding (tie lines)
Gray Duplicate destinations
Table 7. Color and Function for Menus
Menu Color Function
Green Primary boards
Cyan Redundant boards
