74
Cable bundle diameter (mm) Space between bundles (mm)
30 200 to 300
• Do not tie cables or bundles in a knot.
• The metal parts of the crimped cold-pressed terminal blocks (such as air switch) cannot protrude
beyond the blocks.
Cabling examples
Figure 59 Fiber cabling example
