35
Figure 32 Static NAT
2. In the Static Address Mapping area, click Add to enter the Add Static Address Mapping page.
Figure 33 Adding static address mapping
3. Configure a static address mapping as described in Table 8 .
4. Click Apply.
Table 8 Configuration items
Item Description
Internal VPN Instance
Specify a name of the VPN instance to which the internal IP addresses belong.
If no internal VPN instance is specified, this indicates that the internal address is
a common private network address.
Internal IP Address Enter an internal IP address for the static address mapping.
Global VPN Instance
Specify a name of the VPN instance to which the external IP addresses belong.
If no global VPN instance is specified, this option indicates that the external
address is a common public network address.
Global IP Address Enter a public IP address for the static address mapping.
Network Mask
Specify the network mask for internal and public IP addresses.
If the network mask is specified, net-to-net static NAT is implemented. If no
network mask is specified, the default mask 255.255.255.255 is used. In this
case, one-to-one static NAT is delivered.
ACL Set an ACL ID for the static NAT policy.
