Installation guide – ACTi Outdoor PTZ / Speed Dome (I9x) on Horizontal Pole with Pendant Mount User Manual
Page 16
Installation Guide
4.
Insert the sealing rubber and attach it at the end of the flexible conduit.
5.
Attach one (1) supplied rubber ring on the gland body (smooth end).
NOTE:
Make sure the rubber ring is completely aligned on the gap on the gland body.
6.
Attach the gland body to the Ethernet port of the camera.
IMPORTANT!
Make sure the rubber ring is completely aligned and flat on the gland body
to avoid
possible water leakage.
