How to Waterproof the Cable Using the Cable Gland
1.
Prepare the following items:
Cable Gland
Gland Rubber Ring
Exterior-Grade
Ethernet Cable
Waterproof Tape
NOTE:
The washer will
not be used in this
installation, please set it
aside.
NOTE:
Not included
in the camera
package.
NOTE:
Not included
in the camera
package.
2.
Detach the cable gland as shown below.
3.
Insert the clamping nut through the Ethernet cable.
Gland Body
Clamping Nut
Sealing Rubber and Claw
Washer
