30 CHAPTER 3 • SENSORS PAGE
Note
Settings can only be saved by clicking Logout on the main menu bar. Ending the
session by closing the browser will revert the display settings to their last saved
state.
Filter Controls
The filter controls, located directly above the sensor list, allow you to specify which sensors
to include in the sensor list; the sensors can be filtered by network, type, status and data. If
no sensors meet the given criteria, the sensor list will be empty. The default values for each
filter control (All, All, Any and Any) will display all of the sensors that are defined within
Collector (see Figure 3.8).
Figure 3.8 – Filter Controls
Clicking on a filter setting will reveal a list of filtering options. The sections below explain
how to use the different filter controls.
Note
Because sensor status can change through time, a filtered sensor list can also
change. The sensor list is automatically refreshed every 60 seconds.
Showing Sensors in Networks
The Showing Sensors In Networks filter lists each network.
Clicking a network name will display the sensors that belong to that network. More than
one network can be marked. Selecting All will display the sensors from all networks, as well
as the sensors that don’t belong to a network.
Of Type
The Of Type list contains each sensor type currently registered in the system. Selecting a
specific sensor type will display the sensors of that type. Selecting All will display all sensor
types.
