Export Sonic Immersion System Dealer Installation Guide
Note
It is important that the ruler or square
(see picture on previous page) be kept
level and at the top of the recess area
while making these measurements.
2. Use the measurements determined in Step 1 and insert them
into the following formula:
Distance A = ______ Distance B = _______
A + 1” (2.54 cm) = Vertical Position (VP) _________
B + ¾” (1.91 cm) = Horizontal Position
(HP)________
3. Now proceed to Cutting Panel Hole for CD Player
Cutting Panel Hole for CD Player Door
Assembly
1. Using number obtained for the Vertical Position (VP),
measure up from bottom of panel, see Figure 34, and mark
spot with a fine point marker.
33
