Note: 1. Subject to change without notice.
Specification, 2006, Companion Doc-1523 Rev -A Rev Date: 10/31/05
2006 Companion Specifications Dimension One Spas
Shape Rectangular
Seating Capacity 3+
Shell Material Granitex™
Dimensions 84" x 66" x 31" H / (213cm X 168cm x 79cm H)
Corner Radii 9" (23cm)
Water Capacity 210 Gallons (795 Liters)
Dry Weight 500 lbs (227 kg)
Shipping Weight Domestic 500 lbs (227 kg) - Export 550 lbs(250 kg)
Full Weight 2250 lbs (1021 kg)
Skirt Material Synthetic
Poly Floor Yes
Water Treatment System ClearZone® Ready
Plumbing Systems 1
Filters/Coverage 1 / 75 sq. ft.
Gate Valves 0
VCR Jet® - Air Adjustable/Directional 0
VCR Jet® - Rotator 0
VCR Jet® - Dual Rotator 0
VCR Jet® - Multi Port Spinner 0
VCR Jet® - Mini Rotator 2
VCR Jet® - Mini Directional 7
VCR Jet® - Euro Directional 10
VCR Jet® - Euro Rotator 0
VCR Jet® - Mini Directional in NFJ 0
Typhoon Jet 0
Ozone Jet 1
Heater Return Jet 0
Pump Returns 2
Diverter Valves 0
Floor Drains 0
Skimmer 8” Weir
Dynamic Massage Sequencer w/ control panel No
NeckFlex® Jet Pillows 0
Headrest Pillows 3
Stereo system not available
Water Feature n/a
Water Feature Volume control n/a
Cup Holders 0
Tactile Therapy Floor pedastal
Pump Information Domestic (60Hz) Export (50Hz)
Motor Size – Peak (Continuous) HP 4.0 (2.5) Hp 3.6 (2.0) HP
Jet Pumps # of Pumps/Speed One / Dual One / Dual
Circulation pump 0 0
Fountain pump n/a n/a
Electrical System Domestic (60Hz) Export (50Hz)
Voltage 240 240
Amperage 30 1X16 / 2X16 / 1X32
Heater 4.0 kW 2.0 kW
Thermostat Electronic Electronic
Light 1 with optional LED 1 with optional LED
Control System SSPA-1-D13 SSPA-1-D13-CE
Upper Control Programmable Digital Programmable Digital
Auxiliary Upper Control No No
Programmable Yes Yes
General
Water System
Special Features
