Note: 1. Subject to change without notice.
2. Reference DOC-1404 Rev. A
Specification, 2006, Cove Doc-1403 Rev. A Rev Date: 04/28/05
2006 Cove Specifications Dimension One Spas
General Domestic (60Hz) Part # Export (50Hz) Part #
Shape Rectangular Rectangular
Shell Material Acrylic Acrylic
Height 30 in. 76 cm
Width 83 in. 211 cm
Length 76 in. 193 cm
Corner Radii 9 in. 23 cm
Seating Capacity 5 5
Water Capacity 245 Gallons 930 Liters
Dry Weight 580 lbs. 263kg
Shipping Weight 580 lbs. 286kg
Full Weight 2620 lbs. 1188kg
Skirt Material Wood or Synthetic Wood or Synthetic
Poly Floor Yes Yes
Water System
Motor Size – Peak (Continuous) HP 3.0 (1.5) HP 3.6 (2.0) HP
# Pumps/Speed One/Dual 01562-21 One/Dual 01562-34B
Pump Returns 2 01510-559G 2 01510-559G
Plumbing Systems 2 2
VCR Jet ® - Multi Port Spinner 1 01510-416G 1 01510-416G
VCR Jet
® - Rotator
2 01510-415G 2 01510-415G
VCR Jet
® - Mini Rotator
3 01510-445G 3 01510-445G
VCR Jet
® - Mini Directional
4 01510-444G 4 01510-444G
VCR Jet® - Euro Directional 12 01510-492G 12 01510-492G
Ozone Jet 1 01510-201G 1 01510-201G
Filters/Coverage 1 / 75 sq. ft. 1 / 6.97 sq. meters
Filter Lid Yes 01510-102 Yes 01510-102
ClearZone® Ready Yes 01512-86 Yes 01512-84
Ozone Ready Yes 03200-10 Yes 03200-10E
Diverter Valves 1 01522-51G 1 01522-51G
Skimmer 8” Weir 01510-137G 20 cm Weir 01510-137G
Electrical System
Voltage 120/240 240
Amperage 15/30/40 1x16 / 2X16 / 1x32
Heater 4.0 KW 01563-21 2.0 KW 01563-21E
Thermostat Electronic Electronic
Light 1 with optional LED 01512-003 (O) 1 with optional LED 01512-003 (O)
Top Side Control Programmable Digital 01560-345 Programmable Digital 01560-345
Control System SSPA-1-D13 01782-1000 SSPA-1-D13-CE 01782-1000
Programmable Yes Yes
