Note: 1. Subject to change without notice.
Specification, Triad II Doc-1514 Rev -B Rev Date: 4/6/07
Triad II Specifications Dimension One Spas
Shape Rectangular
Seating Capacity 3
Shell Material Ultralife™ / Granitex™ / Geloy®
Dimensions 83½" x 66½" x 30½" H / (212cm X 169cm x 77cm H)
Corner Radii 16" (41 cm)
Water Capacity 200 Gallons (757 Liters)
Dry Weight 640 lbs (291 kg)
Shipping Weight Domestic 640 lbs (291 kg) - Export 690 lbs (313 kg)
Full Weight 2310 lbs (1048 kg)
Skirt Material Domestic Synthetic - Export Wood or Synthetic
Poly Floor Yes
Water Treatment System Ultra Pure™
Plumbing Systems 1
Filters/Coverage 2 / 75 sq. ft.
Gate Valves 2
VCR Jet® - Air Adjustable/Directional 4
VCR Jet® - Rotator 7
VCR Jet® - Dual Rotator 0
VCR Jet® - Multi Port Spinner 0
VCR Jet® - Mini Rotator 2
VCR Jet® - Mini Directional 6
VCR Jet® - Euro Directional 0
VCR Jet® - Euro Rotator 0
VCR Jet® - Mini Directional in NFJ 4
Typhoon Jet 0
Ozone Jet 1
Heater Return Jet 1
Pump Returns 2
Diverter Valves 0
Floor Drains 1
Skimmer 8” Weir
Dynamic Massage Sequencer w/ control panel Yes
NeckFlex® Jet Pillows 1
Headrest Pillows 2
Stereo system Optional Advanced In.Tune
Water Feature n/a
Water Feature Volume control n/a
Cup Holders 2
Tactile Therapy Foot & hand
Pump Information Domestic (60Hz) Export (50Hz)
Motor Size – Peak (Continuous) HP 4.0 (2.5) Hp 3.6 (2.0) HP
Jet Pumps # of Pumps/Speed One / Dual One / single
Circulation pump 1 1
Fountain pump n/a n/a
Electrical System Domestic (60Hz) Export (50Hz)
Voltage 240 240
Amperage 40/30 1X16 / 2X16 / 1X32
Heater FastFlo 2.7,4.0,5.5 kW FastFlo 2.9 kW
Thermostat Electronic Electronic
Light 1 with optional LED Multi color LED
Control System MSPA-MP-D17 MSPA-MP-CE-D17
Upper Control (programable) M-Drive with Scrolling Message Center M-Drive with Scrolling Message Center
Auxiliary Upper Control No No
General
Water System
Special Features
