Dimension One Spas AquaPro 19 - Manual

Page 1 of 2
Note: 1. Subject to change without notice.
2. * For builder's pack models the following equipment is not supplied.
Ozone Jets, Heater return jet, water treatment system, heater,
thermostat, upper control, control system and pumps.
3. ** Builder's pack light is an incandescent bulb.
Specification, 2006, Aqua Pro 19' Doc-1521 Rev -A Rev Date: 10/31/05
2006 Aqua Pro 19' Specifications Dimension One Spas
Shape Oval
Seating Capacity n/a
Shell Material DuraTex™
Dimensions 90¼" x 228" x 62" H / (229cm X 579cm x 157cm H)
Corner Radii N/A
Water Capacity 2400 Gallons (9085 Liters)
Dry Weight 3600 lbs (1633 kg)
Shipping Weight 3600 lbs (1633 kg)
Full Weight 23600 lbs (10705 kg)
Skirt Material Wood optional
Water Treatment System CD - Ozone*
Plumbing Systems 2
Filters/Coverage 2 / 75 sq. ft.
Gate Valves 8
VCR Jet® - Air Adjustable/Directional 0
VCR Jet® - Rotator 0
VCR Jet® - Dual Rotator 0
VCR Jet® - Multi Port Spinner 0
VCR Jet® - Mini Rotator 4
VCR Jet® - Mini Directional 8
VCR Jet® - Euro Directional 0
VCR Jet® - Euro Rotator 0
VCR Jet® - Mini Directional in NFJ 4
Typhoon Jet 0
Swim Jets 6
Ozone Jet 2 *
Heater Return Jet 1 *
Pump Returns 5
Diverter Valves 1
Floor Drains 1
Skimmer 2 - 8” Weir
NeckFlex® Jet Pillows 1
Headrest Pillows 0
Optimounts™ 14
Tether Mount 2
Swim Bar 1
Swim Jet Air Valves 2
Swim Tether 1
Pump Information Domestic (60Hz) Export (50Hz)
Motor Size – Peak (Continuous) HP 5.0 (3.0) HP 3.6 (2.0) HP
Jet Pumps # of Pumps/Speed One / Dual & Two / Single One / Dual & Two / Single
Circulation pump 0 0
Electrical System Domestic (60Hz) Export (50Hz)
Voltage 240 240
Amperage 60 or 60 (htr) + 50 (pumps) 60 or 60 (htr) + 50 (pumps)
Heater 11 kW * 11 kW *
Thermostat Electronic * Electronic *
Light 2 Multi color LED** 2 Multi color LED**
Control System Spa Builders * Spa Builders *
Upper Control Spa Builders * Spa Builders *
General
Water System
Special Features
