Note: 1. Subject to change without notice.
Specification, 2006, Seville Doc-1515 Rev -A Rev Date: 10/31/05
2006 Seville Specifications Dimension One Spas
Shape Rectangular
Seating Capacity 5
Shell Material Ultralife™ / Granitex™ / Geloy®
Dimensions 84" x 78" x 30" H / (213cm X 198cm x 76cm H)
Corner Radii 16" (41 cm)
Water Capacity 260 Gallons (985 Liters)
Dry Weight 670 lbs (304 kg)
Shipping Weight Domestic 670 lbs (304 kg) - Export 720 lbs (327 kg)
Full Weight 2840 lbs (1288 kg)
Skirt Material Domestic Synthetic - Export Wood or Synthetic
Poly Floor Yes
Water Treatment System Ultra Pure™
Plumbing Systems 2
Filters/Coverage 2 / 75 sq. ft.
Gate Valves 2
VCR Jet® - Air Adjustable/Directional 0
VCR Jet® - Rotator 2
VCR Jet® - Dual Rotator 0
VCR Jet® - Multi Port Spinner 0
VCR Jet® - Mini Rotator 2
VCR Jet® - Mini Directional 14
VCR Jet® - Euro Directional 13
VCR Jet® - Euro Rotator 6
VCR Jet® - Mini Directional in NFJ 4
Typhoon Jet 0
Ozone Jet 1
Heater Return Jet 1
Pump Returns 2
Diverter Valves 1
Floor Drains 1
Skimmer 8” Weir
Dynamic Massage Sequencer w/ control panel No
NeckFlex® Jet Pillows 1
Headrest Pillows 1
Stereo system Optional Wireless* * Wireless stereo not available for export
Water Feature n/a
Water Feature Volume control n/a
Cup Holders 3
Tactile Therapy Foot
Pump Information Domestic (60Hz) Export (50Hz)
Motor Size – Peak (Continuous) HP 4.0 (2.5) Hp 3.6 (2.0) HP
Jet Pumps # of Pumps/Speed One / Dual One / single
Circulation pump 1 1
Fountain pump n/a n/a
Electrical System Domestic (60Hz) Export (50Hz)
Voltage 240 240
Amperage 40/30 1X16 / 2X16 / 1X32
Heater FastFlo 2.7,4.0,5.5 kW FastFlo 2.9 kW
Thermostat Electronic Electronic
Light 1 with optional LED Multi color LED
Control System MSPA-MP-D12 MSPA-MP-D11-CE
Upper Control Scrolling Message Center Scrolling Message Center
Auxiliary Upper Control No No
Programmable Yes Yes
General
Water System
Special Features
