Dimension One Spas Nautilus - Manual

Page 1 of 2
Note: 1. Subject to change without notice.
Specification, Nautilus Doc-1480 Rev -C Rev Date: 4/6/07
Nautilus Specifications Dimension One Spas
Shape Square
Seating Capacity 7
Shell Material Ultralife™ / Granitex™ / Geloy®
Dimensions 91½" x 91½" x 36" H / (232cm X 232cm x 91.4cm H)
Corner Radii 16" (41 cm)
Water Capacity 370 Gallons (1324 Liters)
Dry Weight 885 lbs (401 kg)
Shipping Weight 885lbs (424 kg)
Full Weight 3967 lbs (1800 kg)
Skirt Material
Poly Floor
Yes
Water Treatment System Ultra Pure™
Plumbing Systems 4
Filters/Coverage 2 / 75 sq. ft.
Gate Valves 4
VCR Jet® - Air Adjustable/Directional 2
VCR Jet® - Rotator 5
VCR Jet® - Dual Rotator 3
VCR Jet® - Multi Port Spinner 3
VCR Jet® - Mini Rotator 12
VCR Jet® - Mini Directional 4
VCR Jet® - Euro Directional 4
VCR Jet® - Euro Rotator 0
VCR Jet® - Mini Directional in NFJ 8
Typhoon Jet 1
Ozone Jet 1
Heater Return Jet 1
Pump Returns 4
Diverter Valves 2
Floor Drains 1
Skimmer 8” Weir
Dynamic Massage Sequencer w/ control panel No
NeckFlex® Jet Pillows 2
Headrest Pillows 2
Stereo system Optional Advanced In.Tune
Water Feature Optional with LFX package
Water Feature Volume control Optional with LFX package
Cup Holders 3
Tactile Therapy Foot & hand
Pump Information Domestic (60Hz) Export (50Hz)
Motor Size – Peak (Continuous) HP 4.0 (2.5) Hp 3.6 (2.0) HP
Jet Pumps # of Pumps/Speed Two / Dual Two / single
Circulation pump 1 1
Fountain pump n/a n/a
Electrical System Domestic (60Hz) Export (50Hz)
Voltage 240 240
Amperage 50/40/30 1X16 / 2X16 / 1X32
Heater FastFlo 2.7,4.0,5.5 kW FastFlo 2.9 kW
Thermostat Electronic Electronic
Light 1 with optional LED Multi color LED
Control System MSPA-MP-D17-NON LFX, MSPA-MP-D18 LFX MSPA-MP-CE-D17-N/LFX, -D18 LFX
Upper Control (programmable) M-Drive with Scrolling Message Center M-Drive with Scrolling Message Center
Auxiliary Upper Control Yes Yes
Special Features
General
Water System
Domestic Synthetic - Export Wood or Synthetic
