Note: 1. Subject to change without notice.
Specification, Lotus Bay Doc-1518 Rev -B Rev Date: 4/6/07
Lotus Bay Specifications Dimension One Spas
Shape Free form / Square
Seating Capacity 7
Shell Material Ultralife™ / Geloy®
Dimensions 91¾" x 91¾" x 40" H / (233cm X 233cm x 102cm H)
Corner Radii 22" (56 cm)
Water Capacity 375 Gallons (1420 Liters)
Dry Weight 1100 lbs (499 kg)
Shipping Weight Domestic 1100 lbs (499 kg) - Export 1150lbs (531 kg)
Full Weight 4225 lbs (1917 kg)
Skirt Material Synthetic
Poly Floor Yes
Water Treatment System Ultra Pure™
Plumbing Systems 5
Filters/Coverage 2 / 75 sq. ft.
Gate Valves 6
VCR Jet® - Air Adjustable/Directional 2
VCR Jet® - Rotator 6
VCR Jet® - Dual Rotator 0
VCR Jet® - Multi Port Spinner 0
VCR Jet® - Mini Rotator 22
VCR Jet® - Mini Directional 4
VCR Jet® - Euro Directional 12
VCR Jet® - Euro Rotator 14
VCR Jet® - Mini Directional in NFJ 8
Typhoon Jet 1
Ozone Jet 1
Heater Return Jet 1
Pump Returns 6
Diverter Valves 2
Floor Drains 1
Skimmer 8” Weir
Dynamic Massage Sequencer w/ control panel Yes
NeckFlex® Jet Pillows 2
Headrest Pillows 4
Stereo system Optional Advanced In.Tune
Water Feature Yes
Water Feature Volume control Yes
Cup Holders 4
Tactile Therapy Floor pedastal
Under water magnetic switch Yes
Air Control Valve No
Pump Information Domestic (60Hz) Export (50Hz)
Motor Size – Peak (Continuous) HP 3.6 (2.0) HP 3.6 (2.0) HP
Jet Pumps # of Pumps/Speed One / Dual & Two / Single One / Dual & Two / Single
Circulation pump 1 1
Fountain pump 1 1
Electrical System Domestic (60Hz) Export (50Hz)
Voltage 240 240
Amperage 50/40 2X16 / 1X32 | 3X16
Heater FastFlo 2.7,4.0,5.5 kW FastFlo 3.3 kW | 2.1, 5.2 kW
Thermostat Electronic Electronic
Light 2 Multi color LED 2 Multi color LED
Control System MSPA-MP-D16 MSPA-MP-D14-CE
Upper Control (programmable) M-Drive with Scrolling Message Center M-Drive with Scrolling Message Center
Auxiliary Upper Control No No
General
Water System
Special Features
