Audio Meter Scales and Ballistics
NORDIC:
Overall dynamic range: 54dB (+12 to -42dB)
Attack time: 10mSec
Decay time: 1.7Sec per 20dB decay
DIN PPM:
Overall dynamic range: 55dB (+5 to -50dB)
Attack time: 10mSec
Decay time: 1.5Sec per 20dB decay
BBC PPM:
Overall dynamic range: 24dB +3dB down "Mark 1" (+12 to
-12dB)
Attack time: 10mSec
Decay time: 2.8Sec per 24dB decay (from "Mark 7" to "Mark 1")
VU:
Overall dynamic range: 23dB (+3 to -20dB)
Attack time: 300mSec
Decay time: 300mSec per 20dB decay
VU EXT:
Overall dynamic range: 60dB (+10 to -50dB)
Attack time: 300mSec
Decay time: 300mSec per 20dB decay
AES/EBU:
Overall dynamic range: 60dB (0 to -60dB)
Attack time: < 5ms
Decay time: 1.5Sec per 20dB decay
Phase Correlation Display
Attack time: 0.4Sec for zero to ±1 deviation
Decay time: 0.4Sec for ±1 to zero deviation
Input dynamic range: 45dB
Minimum input level: -45dBu
Mechanical
3U 19” Rack Mounting Frame with removable front panel, temperature controlled fan assisted
ventilation, 20 card slots, separate rear connector modules and power supply / fan status indicators.
Two versions:
SV-S: Single multi-viewer with up to 64 video inputs
SV-D: Two separate multi-viewers, each with up to 32 video inputs
Outline Dimensions: 484mm(W) x 462mm(D) x 132mm(H)
Weight: 19kg (full frame)
Power
Autosensing 84 – 260 V AC, 50/60Hz switch mode internal power supply
Low voltage 12 - 24V DC
Maximum power consumption 190W (fully loaded frame with 16 x 3G video sources)
Environmental
Temperature 0°C to 30°C Humidity 70% max
I/O Cards (all hot swappable)
Video
VIP1: composite, SDI, DVI-I, S-Video, RGB/YUV 4 x video input
VIP2: as VIP1 with HD-SDI (up to 3G) 4 x video input
VidLoop: 4 x video loop through (requires two card slots)
