SIERRA VIEW
25
Video card GPI I/O pin assignments
Female 15 way ‘D’ connector assignments
Audio I/O connector pin assignments
Female 44 way ‘D’ connector analog audio I/O assignments channels 1 – 16
Pin No
Function
1
GPI In 1
2
GPI In 2
3
GPI In 3
4
GPI In 4
5
GND
6
GPI In 5
7
GPI In 6
8
GPI In 7
9
GPI In 8
10
GND
11
GPI Out 1
12
GPI Out 2
13
GPI Out 3
14
GPI Out 4
15
GND
Analogue In/Out
+VE
-VE
GNDs
Ch 1
15
30
Ch 2
14
29
Ch 3
13
28
Ch 4
12
27
Ch 5
11
26
Ch 6
10
25
Ch 7
9
24
Ch 8
8
23
Ch 9
7
22
Ch 10
6
21
Ch 11
5
20
Ch 12
4
19
Ch 13
3
18
Ch 14
2
17
Ch 15
1
16
Ch 16
33
34
Grounds
31, 32, 35-44 inc.
