SIERRA VIDEO
24
Global GPI I/O pin assignments
Female high density 26 way ‘D’ connector assignments
Pin No Function
1 GPI In 1
2 GPI In 4
3 GPI In 7
4 GPI In 10
5 GPI In 13
6 GPI Out 0
7 GPI Out 3
8 GPI Out 6
9 GND
10 GPI In 0
11 GPI In 3
12 GPI In 6
13 GPI In 9
14 GPI In 12
15 GPI In 15
16 GPI Out 1
17 GPI Out 4
18 GPI Out 7
19 GPI In 2
20 GPI In 5
21 GPI In 8
22 GPI In 11
23 GPI In 14
24 GPI Out 2
25 GPI Out 5
26 5V (via 0.5A resettable fuse)
