SIERRA VIEW
17
The illustration above shows the internal layout with a double rear fitted.
The illustration above shows the internal layout with a single rear module fitted.
When double width rear connector modules are used, the input capacity of the Sierra
View is reduced. For example, if the unit were to be configured for DVI inputs only, dual
width rear modules would be required (RM-SV42), each carrying 4 x DVI ports. In this
case, the total video input capacity of the frame is reduced from a possible 64 to 32
inputs. Eight video input cards and eight video loop cards would be needed for this
configuration to work, which would fully populate the 16 usable video card slots in the
frame.
Single Rear
Connector with
One PCB
Video Input Card
Double Width Rear
with Two PCBs
Video Loop
Card
Video I/P
Card
