WEB OPERATION
QC40198 User Manual
110 | P a g e
Snapshot
Snapshot interface is shown in Figure 7-55.
Figure 7-55
Please refer to the following chart for detailed information.
Parameter Function
Channel It is the monitor channel.
Snapshot mode
There are two modes: Timing and activation.
Frame rate You can select from the dropdown list. The value ranges from
1f/s to 7f/s.
Resolution
Supports D1 resolution.
Quality
You can select from the dropdown list. Here you set video
quality.
There are six options: 10%, 30%, 50%, 60%, 80%, 100%.
100% is the best quality.
