WEB OPERATION
QC40198 User Manual
107 | P a g e
Alarm I/O
Here you can search alarm output status. See Figure 7-51.
Figure 7-51
Important
The alarm output port should not be connected to high power load directly (It should be less than 1 Amp) to avoid
high current which may result in relay damage. Please use the co-contactor to establish the connection between the
alarm output port and the load.
Please refer to the following chart for detailed information.
Parameter Function
Alarm output There are three output channels (Multiple choices).
Activate Enable/disable alarm output device. After the Web activated the
alarm, you need to cancel the channel and then click the trigger
button to cancel the alarm, or you need to cancel the alarm in the
pop-up dialogue box in local-end.
Refresh
Search alarm output status.
