WEB OPERATION
QC40198 User Manual
103 | P a g e
Parameter Function
Normal
out  There is 2-channel alarm output.
 Corresponding to motion detection alarm output port (multiple
choices)
 Enable alarm activation function. You need to select alarm output port
so that system can activate corresponding alarm device when alarm
occurs.
Alarm
latch
System can delay the alarm output for specified time after alarm ends.
The value ranges from 10s to 300s.
Alarm
upload System can upload the alarm signal to the centre (Including alarm
centre.
Record
channel System auto activates motion detection channel (multiple choices) to
record once alarm occurs (working with motion detection function).
Please note current device shall be in alarm record period (Chapter
7.3.2.3 Schedule) and you have enabled the schedule record function
in chapter 7.3.3.3 Record.
Record
latch System can delay the record for specified time after alarm ends. The
value ranges from 10s to 300s.
Email If you enabled this function, System can send out an email to alert you
when alarm occurs and ends.
Tour  Display the selected video in local monitor window.
 Tour interval and tour mode are set in combo DVR local menu
(chapter 5.3.9 Display )
PTZ
Activation  Here you can set PTZ movement when alarm occurs. Such as go to
preset x when there is an alarm.
Capture You need to input capture channel number so that system can backup
motion detection snapshot file.
Copy This is a shortcut menu button. You can copy current channel setup to
one or more (all) channels.
Save You can click save button after you complete setup for one channel, or
you can complete the whole setup and then click save button.
Refresh Click this button to get device’s latest configuration information.
