DI-1162 Remote Access Router
Appendix A – Cables and Connectors 137
18 10 Local Loopback LL DTE
19 25 RTS CA DTE
20 12 DTR CD DTE
21 14 Remote Loopback RL DTE
22 29 DSR CC DCE
23 30 DTR CD DTE
24 17 TXD CLK DA DTE
25 18 Test Mode TM DCE
End Connector: DB-25 Pin Female (ISO-2110)
DB-37 Pin Male
Cable Length: 1.5 m
V.35 Cable for WAN Port
DB25
Female
Pin
Number
V.35
Male Pin
Number
Signal Name Mnemonic Source
1 A Protective Ground - -
2 P TXD 103 DTE
3 R RXD 104 DCE
4 C RTS 105 DTE
5 D CTS 106 DCE
6 E DSR 107 DCE
7 B Signal Ground 102 -
8 F Rec. Line Signal Det. 109 DCE
9 X RXD CLK 115 DCE
10
11
W TXD CLK 113 DTE
12 AA TXD CLK 114 DCE
13
14
S TXD 103 DTE
15 Y TXD CLK 114 DCE
16 T RXD 104 DCE
17 V RXD CLK 115 DCE
18
19
20
H DTR 108 DTE
21
22
