MDE-4695 CFN Series Unitec® PC Interface for Site Controller III Version 3.6 and Later · July 2010 Page 1
Purpose Introduction
1 – Introduction
Purpose
This manual provides instructions to connect a CFN Series Site Controller (SC) (Version 3.6
and later) to the Unitec
® POS 4000 Car Wash Controller using a Unitec PC Interface.
Overview
The Unitec PC interface from the SC III PC port to the Unitec POS 4000 Car Wash Controller,
uses RS-232 communication. This interface is connected directly to the Car Wash Controller,
and eliminates the need for the Gasboy
® SDI Interface Box.
The Unitec unit must be equipped with Uni-CAM Mark VII option, version 6.2 hardware,
unless otherwise specified by the Unitec specification. Set the Unitec unit for 2400 baud
operation, on the Unitec Serial Port. Gasboy supports the Uni-CAM protocol used by Unitec.
For the appropriate settings, refer to Unitec documentation.
Related Documents
CFN III - Version 3.4 and Later
Document Number Title GOLD Library
C35923 Point of Sale and Shift Change, Version 003 Gasboy CFN Series Controllers and POS
MDE-4298 CFN Series SC III Installation Manual Gasboy CFN Series Controllers and POS
MDE-4299 CFN Series Profit Point Installation Manual Gasboy CFN Series Controllers and POS
MDE-4355 Profit Point Clerk’s Manual Gasboy CFN Series Controllers and POS
MDE-4356 Profit Point Reference Manual Gasboy CFN Series Controllers and POS
MDE-4479 CFN III Quick Reference Guide Version 3.4 Gasboy CFN Series Controllers and POS
MDE-4871 CFN III Manager’s Manual for Windows XP ®
Embedded Version 3.6
Gasboy CFN Series Controllers and POS
MDE-4872 CFN Series CFN III Configuration Manual for
Windows XP Version 3.6 Gasboy CFN Series Controllers and POS
MDE-4873 CFN Series Site Controller III Start-up Manual for
CFN III Versions 3.6 and Later Gasboy CFN Series Controllers and POS
MDE-4874 CFN Series NBS (GL3) Credit and Debit Card
Network -Version 1.4.0.0 and Later, for CFN III
Versions 3.6 and Later
Gasboy CFN Series Controllers and POS
