MDE-4282B Gasboy Pulser Kits M04230K00X Installation • July 2005
Page 3
Introduction
Parts Lists
M04230K001 - KIT-PLSR CX 9100QTW2, QXTW2 10:1
M04230K002 - KIT-PLSR CC 9100QTW2,QXTW2 100:1
Part Number
Description
Quantity
056895
SPACER TOP .835 NOM.LGTH
2
051806
SCR 1/4-28X5/8 HHC
6
068891
WASHER,LOCK EXT 1/4 1114
14
046970
PLATE-MOUNTING PULSER 100:1
2
056877
SPACER .944 NOM.LENGTH (F)
4
046973
PLSR & CPLG ASSY;10:1
2
025015
ELBOW-CONDUIT 1/2 X 45 M/F MCH
2
023944
CONDUIT-BENT PULSER1 TWIN
1
066400
1/2"UNY EXP PROOF COND UNION
3
064830
CONDUIT TEE, MACHINED
1
023946
CONDUIT-BENT PULSERS T TWIN
1
051805
SCR 1/4-20X5/8 HHC PL
6
043225
PIN SPIROL 5/64X7/16 CRS ZINC
2
031035
HUB-QUAN. SHAFT EXTENSION
2
027041
GEAR, QUANTITY
2
049406
RING RET 5133-25-ZF
2
027044
PLATE AND IDLER GEAR ASSY
2
053920
SCR 1/4-20X5/8 WSH HD TYP T
2
023945
CONDUIT-BENT PULSER2 TWIN
1
025045
ELBOW-CONDUIT 1/2 X 90 M/F MCH
1
C08682
TIE-WRAP,IDENTIF(1"X5/16) 5/8D
2
MDE-4282
Pulser Kit Installation Manual
1
047401
POLY BAG 5 X 6
1
018656
CRTN 14.312 X 11.375
1
Part Number
Description
Quantity
056895
SPACER TOP .835 NOM.LGTH
2
051806
SCR 1/4-28X5/8 HHC
6
068891
WASHER,LOCK EXT 1/4 1114
14
046970
PLATE-MOUNTING PULSER 100:1
2
056877
SPACER .944 NOM.LENGTH (F)
4
046972
PLSR & CPLG ASSY;100:1
2
025015
ELBOW-CONDUIT 1/2 X 45 M/F MCH
2
023944
CONDUIT-BENT PULSER1 TWIN
1
066400
1/2"UNY EXP PROOF COND UNION
3
064830
CONDUIT TEE, MACHINED
1
023946
CONDUIT-BENT PULSERS T TWIN
1
051805
SCR 1/4-20X5/8 HHC PL
6
