Installing the Pulser Kit in Single Unit
6
Loosely secure in place with two washers and two screws.
7
After careful examination to ensure that the parts are meshed properly, tighten the screws.
8
Ensuring that the wires are extending through the conduit, install the 066400 union on the
conduit connected to the pulser.
9
Install the 025045 elbow in the top of the junction box.
10
Connect the union to the elbow installed in the junction box. Make sure the wires extend into
the junction box.
Connecting Wires in Junction Box
1
Remove the 12 screws securing the cover on the junction box. Save screws for remounting.
2
Inside the junction box, connect the green ground lead from the pulser to a secure known
ground.
3
Refer to your Fuel Management System installation manual for proper wiring of the pulsers.
4
Using the recommended grease to seal the cover, remount the junction box cover and secure
with the 12 screws removed in Step 1.
Testing/Checking Operation
Only the 10:1 pulser can be tested for operation. Test the 10:1 pulser as follows:
Note: To test other pulsers, a standard transaction must be run. Look at the transaction print
out from the system to ensure proper operation.
1
Restore power to the unit.
2
Connect a mechanical voltmeter on the two orange signal wires.
3
Set the voltmeter to read Ohms.
4
Slowly dispense fuel and observe that the needle deflects upscale for each 1/10 gallon fuel.
Completing Installation
1
After determining that the pulser is functioning properly, remount the dial faces on the
computer and secure with the screws saved during removal.
2
Remount the bezels on both sides of the unit and secure with the screws saved during removal.
3
Remount the doors on both sides of the unit and secure with the keylocks.
4
Inform the manager/owner that the unit can be returned back to service.
