DataSim 6100
Operators Manual
2-14
Table 2-6. Personality Modules (cont.)
MDE Ref # Part # Description Additional Detail
6070-07B 2244467 MCL1 Atrials Normal Sinus Rhythm
Bradycardia
Sinus Arrest
Atrial Tach
Atrial Flutter
Atrial Fib
PAC
PAT
6070-08B 2244471 MCL1 Blocks Normal Sinus Rhythm
1 st degree AV block
2 nd degree AV block Type I
2 nd degree AV block Type II
3 rd degree AV block
RBBB
LBBB
6070-09B 2244480 MCL1 Ectopy/
Aberrancy
Normal Sinus Rhythm
Right PVC
Left PVC
Multifocal PVC’s
R on T
Bigeminy
Atrial Fib with Aberrancy
Cardiac Failure Sequence
6070-11B 224448 Left Heart
Pressures
Pressure Zero
Normal AO, LV, LA
AO to LV Insertion
LV to AO Pullback
AO, LV, and LA with PVCs
6070-12B 2244500 Valve Disease Mitral Stenosis
Mitral Regurgitation
Aortic Stenosis
Aortic Regurgitation
LV/AO Pullback with AS
LV/AO Pullback with AR
6070-13B 2244517 12-Lead Set Includes three previous
modules
6070-14B 2244521 12-Lead Normal
ECG
