The Venus 1500 Message Studio
Tutorial
72
On the right side of the window, it is possible
to choose from different options by clicking
on the Options button. Refer to Figure 99.
The Video Import Options provides
different methods for importing the message.
The following possibilities are available:
place image(s) on existing frame(s),
place image(s) on new frame(s),
import image(s) into graphic box(es)
import image(s) on background of the
frame(s).
Choose the desired option and click OK.
The Stretch to Fit option makes the files adjust to the display size. When this box is checked,
the Smoothing box will be enabled. Check the Smoothing box to improve the quality of the
imported AVI file as it stretches to fit the display dimensions.
1.
Click on the slider bars to make the desired adjustments.
2.
Click Reset to void any corrections and return to the original settings.
3. The AVI can also be converted to a grayscale file by checking the box next to Convert
to Grayscale.
Once all the settings are established, click Import. The video file will be imported into the
Message Studio and is ready to be previewed.
Figure 99: Video Import Options
