Venus 1500 Real-Time
Tutorial
142
Before creating an RTD or Real Time Data message in the Message Studio, configurations need
to be set up in the Real Time application.
Configure Inputs
The first step is to configure an input to capture and display real-time data. An input source
consists of a port and an .itf or Input Template File. The input source port can either be UDP,
serial, IPX, TCP, or HTTP. The .itf file is a filter to the data coming in on the input port. This
file captures the desired data from the raw feed coming in from the input source.
To configure an input,
1.
In the main Real Time window (Figure 169), highlight the input entry to be configured.
2. Click Edit.
3.
Select Inputs.
4.
Select New to open the Input
Properties window (Figure 170).
Figure 169: Real-time Window
Figure 170: Input Properties Window
