MBT-4000B Multi-band Transceiver System Revision 1
Serial-based Remote Product Management MN/MBT4000B.IOM
6–16
Parameter
Type
Command
(Instruction Code
and qualifier)
Valid on
MBT or
BUC/BDC
Arguments for
Command or
Response to
Query
Description of Arguments
(Note that all arguments are ASCII numeric codes – i.e., ASCII codes
between 48 and 57)
Response to Command
(Target to Controller)
Query
(Instruction
Code and
qualifier)
Response to
Query
(Target to
Controller)
Online Status N/A MBT N/A Query only.
Returns the online status of the unit (useful in redundant configurations) in
the form x.
Return position of corresponding RF switch.
Example for MBT-4000B base unit:
<0001/ONL?{cr}
>0001/ONL={cr}{lf}
ON1=ON ,{cr}
ON2=ON , {cr}{lf}
Example for BDC:
<0001A1/ONL?{cr}
>0001A1/ONL=1{cr}{lf}
Example for BUC:
<0001A2/ONL?{cr}
>0001A2/ONL=1{cr}{lf}
ONL=
ONL?
ONL? ONL=x
Retrieve
AUX
COMM I/O
N/A MBT 1 byte, numeric Query only.
Used to Retrieve AUX COMM I/O of the MBT-4000B base unit, in the form
n, where:
n=1 (AUX COMM)
Example: <0001/RAI?1
Returns:
>0001/RAI=
12V1=On
IO1A=0
IO1B=1
RSVD=0
Note: 0=Logic low or input voltage < 0.5 vdc.
1=Logic level 1 or input voltage > 2.7 vdc.
RAI=
RAI?
RAI*
RAI?n RAI=x
(see Description of
Arguments for
details)
Redundancy
Mode
RAM=um MBT 2 bytes, numeric Command or Query.
Sets or returns redundancy mode in the form um, where:
u=1 (Unit 1) or 2 (Unit 2)
m=0 (Manual Mode) or 1 (Automatic Mode)
Example: RAM=11
RAM=
RAM?)
RAM*
RAM?u RAM=um
(same format as
command
arguments)
