MBT-4000B Multi-Band Transceiver System Revision 1
System Operating Parameters MN/MBT4000B.IOM
4–3
4.5 Block Up Converter Module (BUC-4000) Operating Parameters
The BUC-4000 translates an L-Band output carrier to the desired output frequency (C-, X-, Ku,- or
Ka-Band) with an output level capable of driving a High-Power Amplifier (HPA).
Table 4-1. BUC-4000 C-, X-, Ku-, and Ka-Band Operating Parameters
Band Frequency LO Frequency Inverting
C-Band 5850 to 6650 MHz 4900 MHz No
X-Band 7900 to 8400 MHz 6950 MHz No
Ku-Band-W 13.75 to 14.50 GHz 12.800 GHz No
Ka-Band 30.00 to 31.00 GHz
Notes:
1. No spectral inversion.
2. 10dB gain adjustment.
