MBT-4000B Multi-band Transceiver System Revision 1
Updating Firmware MN
/MBT4000B.IOM
5–2
5.2 Getting Started: Preparing for the Firmware Download
Item Description
1 J1 | Power Connection
2 J2 | COMM Connection
3 LED Indicators
4 Optional Comtech EF Data System Programming Cable (CEFD P/N CA/WR12243-1)
5 User PC with available serial port
Figure 5-1. MBT-4000B Firmware Update – Minimum Requirements
1. First, identify the firmware number and its version number.
A. User-supplied items needed (Figure 5-1):
• A Microsoft Windows-based PC equipped with an available serial port and a terminal
emulator program (e.g., Tera Term or HyperTerminal) if needed.
• A 9-pin to 19-pin serial adapter cable, such as the optional Comtech EF Data System
Programming Cable (CEFD P/N CA/WR12243-1).
