Comtech EF Data MBT-4000B - Manual (Page 51)

MBT-4000B Multi-band Transceiver System Revision 1
Updating Firmware MN/MBT4000B.IOM
5–11
Step Task
9 Upon successful completion of the
upload, you may click [Go Back
to Start] (if, for example, more
than one MBT-4000B System
requires update), or click [Close]
to exit the FLSHCSAT program.
10 If needed, disconnect the System
Programming Cable (CEFD P/N
CA/WR12243-1) and reconnect
the original system communication
cable.
11 The LEDs on the MBT-4000B
Base Module will illuminate
GREEN (unmuted) or YELLOW
(muted) to indicate the current
status of the unit.
Note: If either LED illuminates
RED, refer to Appendix B.
FAULTS/EVENTS for further
information.
The MBT-4000B is now operating with its latest firmware. The firmware
update process is now complete.
