MBT-4000B Multi-band Transceiver System Revision 1
Updating Firmware MN/MBT4000B.IOM
5–3
B. On the PC – Configure the terminal emulator program if applicable.
Refer to your terminal emulator program HELP feature or user guide for
operating and configuration instructions.
Configure the utility program serial port communication and terminal display operation:
• 38400 bps (Baud Rate) • 8 Data Bits • 1 Stop Bit
• Parity = NO • Port Flow Control = NONE • Display New line Rx/Tx: CR
• Local Echo = ON
C. On the MBT-4000B – Power up the unit. Your power connection varies depending on your
ordered unit.
See Sect. 3.2.1.2 J1 | POWER in this manual for your specific power
connectors.
D. Obtain the firmware information using serial-based remote product management:
o
Remote Query: <0/FRW? (returns complete Boot, Bulk1 and Bulk2 information)
See Chapter 6. SERIAL-BASED REMOTE PRODUCT MANAGEMENT for more
information on using remote commands/queries.
2. Next, create a temporary folder (subdirectory) on the User PC for the firmware archive
download.
• Drive letter ‘c:’ is used in these examples. Any valid, writable drive letter can be
used.
• Typical for all tasks: Type the command without quotes
There are several ways the user may use create a temporary folder on a Windows-based PC:
, and then press Enter to
execute.
A. Use the Windows Desktop to create and rename the temporary folder.
