MBT-4000B Multi-band Transceiver System Revision 1
Updating Firmware MN/MBT4000B.IOM
5–7
G. Download the archive file to the temporary folder.
• Once the EXE or ZIP hyperlink is selected the ‘File Download’ window opens and
prompts selection of [Open] or [Save]:
o
Click [Open] to turn over file extraction to the user-supplied utility program. Be
sure to extract the firmware files to the ‘temp’ folder created earlier.
o
Click [Save] to open the ‘Save As’ window. Be sure to select and [Save] the
archive *.exe or *.zip file to the ‘temp’ folder created earlier.
Otherwise, click [Cancel] to quit and exit the file download process.
2. Next, extract the firmware files from the archive file.
• (If not already done with File Download > [Open]) Extract the firmware files from the
downloaded *.exe or *.zip archive file with the user-supplied utility program:
o
Double-click on the archive file name, and then follow the prompts provided by the
user-supplied utility program. Extract, at a minimum, four files:
 FW12357X.CCC – The Firmware Bulk image file (where ‘x’ denotes the revision
letter).
 MBT4000B_ReleaseNotes_v#-#-#.pdf – The Firmware Release Notes PDF file
(where ‘#-#-#’ denotes the firmware version number).
 FLSHCSAT.EXE – CEFD Flash Upload Utility Program.
 CCCflash.hlp – FLSHCSAT Help File.
3. Confirm availability of the firmware files in the temporary folder.
There are several ways the user may view the contents of the temporary folder on a
Windows-based PC:
A. From the Windows Desktop:
• Double-left-click the ‘temp’ folder saved to the Windows Desktop.
