HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier MN/HPOD.IOM
External Connectors and Pinouts Revision 8
2–9
2.6 Energize the HPOD SSPA
WARNING! NEVER TURN THE UNIT ON WITHOUT PROPER WAVEGUIDE
TERMINATION ON THE ‘J2 RF OUTPUT’ PORT. INDIVIDUALS CAN BE EXPOSED TO
DANGEROUSLY HIGH ELECTROMAGNETIC LEVELS.
The HPOD SSPA does not contain a ‘Power On/Off’ switch. Power ON the SSPA by connecting
the ‘J3 | AC IN’ Power connector to the appropriate prime power source. The Mute or Transmit
status of the SSPA will automatically come up in the last stored state (factory default = Transmit
on, not muted).
Figure 2-4. HPOD Unit
