HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier MN/HPOD.IOM
Appendix A Revision 8
A–20
A.3.3 ODPA C-Band 1:1 Redundancy Switch/Waveguide Kit (CEFD P/N KT/11799)
Table A-7. ODPA C-Band 1:1 Redundancy Switch/Waveguide Kit (CEFD P/N KT/11799) Parts List
ITEM QTY CEFD P/N DESCRIPTION
1 1 SW/WGS+28V137SC Waveguide, CPR137, 28V, Sealed 3 Form C Relay
2 1 FP/BR11798-1 Bracket, Switch and Load Mounting
3 1 FP/WG11796-1 Waveguide, Left, CPRG-137, SSPA, C-Band
4 1 FP/WG11797-1 Waveguide, Right, CPRG-137, SSPA, C-Band
-5 Not Used
6 2 FP/WG11801-1 Waveguide, Straight, CPRG-137
7 1 RF/C-TERM1000W Termination, Load, 1000 Watt, CPRG-137
8 1 RF/CG-137-40-N Crossguide, WR137, 40 dB, Type N Female
9 Not Used
10 4 GA/CPR-137-R-H-C Gasket, D Shape, CPR-137, Half Thickness,
11 4 GA/CPR137-R-F-C Gasket, Round, CPR137, Full Thickness,
12 thru 19 Not Used
20 40 HW/1/4-20X5/8SHCS Screw, SS
21 40 HW/1/4-FLT Washer, Flat
22 40 HW/1/4-SPLIT Washer, Split
23 32 HW/10-32X1/2SH Screw, Cap
24 16 HW/10-32X7/8SHCS Screw, SS
25 48 HW/10-FLT Washer, Flat
26 48 HW-10-SPLIT Washer, Split
27 thru 29 Not Used
30 1 SW/WG2AGS Switch, CPR229
31 1 RF/CG-229-40-NRV Crossguide, WR137
32 1 RF/ADP-CPR229-N Adapter, Waveguide
33 2 FP/WG11800-1 Waveguide, E Bend
34 thru 99 Not Used
100 2 RF/N-TERM50M1 RF, 50Ω N Male
