Comtech EF Data HPOD User Manual
Page 120
HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier
MN/HPOD.IOM
Appendix A
Revision 8
A–30
A.3.8 Ku-Band 1:1 Redundancy Assembly Kit (CEFD P/N KT/11936-1)
Table A-11. Ku-Band 1:1 Redundancy Assembly Kit (CEFD P/N KT/11936-1) Parts List
ITEM
QTY
CEFD P/N
DESCRIPTION
1
1
SW/WGS+28V-75SB
Switch, +28VDC
2
1
FP/WG11825-1
Waveguide, Straight
3
1
FP/WG11935-1
Waveguide, Right
4
1
FP/WG11934-1
Waveguide, Left
5
1
FP/BR11933-1
Bracket, Switch
6
4
FP/BR11424-1
Bracket, Mounting
7
3
FP/BR11931-1
Bracket, Unistrut
8
2
FP/BR11932-1
Bracket, Unistrut
-9
2
GA/WR75-R-F-C
Gasket, Full Thickness
10
6
GA/WR75-R-H-C
Gasket, Half Thickness
11
1
RF/TERM75/350W
Waveguide, Termination
12 thru 19
Not Used
20
2
HW/1/4SPRINGNUT
Nut, Channel
21
14
HW/3/8SPRINGNUT
Nut, Spring
22
2
HW1/4-20X5/8SHCS
Screw 1/4-20 x 5/8 SHCS, SS
23
2
HW/1/4-SPLIT
Washer, Lock
24
2
HW/1/4-FLT
Washer, Flat
25
38
HW/38-16X1BLT
Bolt, Hex Head
26
38
HW/3/8-SPLIT
Washer, Lock
27
38
HW/3/8-FLT
Washer, Flat
-28
Not Used
29
24
HW/3/8-16HEXNUT
Nut, Hex
30
4
HW/6-32X3/4SHCS
Screw, Socket Head
31
8
HW/6-32X5/8SHCS
Screw, Socket, Head
32
28
HW/6-SPLIT
Washer, Lock
33
32
HW/6-FLT
Washer, Flat
34
4
HW/6-32HEXNUT
Nut, Hex
35
16
HW/6-32X1/2SHCS
Screw, Socket Head
