2.3 RF Signal Interface Connector Group
2.3.1 ‘J1 | RF IN’ Connector
The ‘J1 | RF IN’ (Input) connector is a Type ‘N’ female. Typical input levels (-30 dBm) depend on
desired output power and unit attenuation. To prevent damage to the HPOD SSPA, RF input
levels should not exceed +15 dBm.
2.3.2 ‘J2 | RF OUT’ Connector
WARNING! FOR SAFETY REASONS, NEVER LOOK DIRECTLY INTO THE WAVEGUIDE
OUTPUT.
The ‘J2 | RF OUT’ (Output) connector is a waveguide interface. The flange that is used depends
on the frequency range of the unit.
Table 2-2. ‘J2 | RF OUT’ Waveguide Output Flange
Unit Frequency Band Waveguide Flange
C CPR137G
X CPR112G
Ku WR75G
