Users Manual Sonic Knife w/500 Operation •••• 9
Location of Sonic Knife
The Sonic Knife weighs approximately 25 Lbs. (12Kg). A table of sufficient quality
and strength should be used to support the sonic knife once it is mounted to a suitable
printer.
The Sonic Knife should be located in an area that the ultrasonic noise emitted from
the cutting operation will not affect others. AVERY DENNISON has taken many
steps to keep the Sonic Knife noise to the lowest level. The Sonic Knife is not
recommended for an office environment.
The power source of the Sonic Knife should be a dedicated line. The first sign that
the Sonic Knife is not being supplied with sufficient power is the ultrasonics will stop
cutting, but the rest of the Sonic Knife will appear fully functional.
Unit Specification
Label Size Max: - 2.00" (51mm) web x up to 8" (203 mm) feed
Min: - 5/8" (16mm) web x 1.2" (30.5mm) feed – Also listed in Appendix B
Print Speed Minimum Length
3 IPS 1.2” (30.5 mm)
4 IPS 1.6” (40.7mm)
4.5 IPS 1.8” (45.8mm)
5 IPS 2” (50.8mm)
6 IPS 2.4” (61mm)
7 IPS 2.8” (71.2mm)
Justification Material must be centered over ultrasonic horn.
Sense Mark The sense mark is not required – does not register to a sense mark – The printer controls the cut position
Speed Controlled by speed of printer – See chart in Appendix B.
Stock Polyester woven edge fabric and AVERY DENNISON So-Soft® Products
Interface Cabling to printers and to Sonics
Dimensions 16.0" (406mm) high x 5 1/2" (138mm) wide x 14" (356mm) deep
Weight 25 Lbs. (12Kg).
Electrical 90-132 / 180-265 VAC 50-60Hz 10/5Amp - factory set
Temperature 41°F (5°C) to 104°F (40°C)
Humidity 5% to 90% non-condensing
Options - Flag cutting – (Controlled by printer)
- Spare Parts Kit not required
- International Hardware Kit
The Sonic Knife is a modular design, which can be added to the AVERY
DENNISON fabric printers - including the 500, 545, 636, 656 and 676 thermal
transfer printers.
