Knife spring replacement, Figure 14 – Avery Dennison SNAP Sonic Knife User Manual
Page 28
Users Manual Sonic Knife w/500
Machine Maintenance •••• 28
Knife Spring Replacement
COVER
KNIFE GUARD
POST SCREW & HOLDER
KNIFE BLADE
KNIFE SCREW
GEAR
GUARD
CONVEYOR
EXIT
FIGURE 14
1) Remove knife guard, gear guard and exit conveyor. Remove the knife assembly
and the post screws and holders that secure the knife mount.
