Attaching sonic knife – stacker, Figure 2 – Avery Dennison SNAP Sonic Knife User Manual
Page 15
Users Manual Sonic Knife w/500
Installation •••• 15
Attaching Sonic Knife – Stacker
SONIC KNIFE
POST
STACKER
FIGURE 2
There are two posts on the outfeed end of the Sonic Knife. Slide the stacker onto the
posts. Adjust the stacker backward/forward and will pivot so the cut labels stack
uniformly. Connect cable per electrical schematic.
