Users Manual Sonic Knife w/500

Machine Maintenance •••• 25

Exit Conveyor

KNIFE
GUARD

CONVEYOR
TOP

ROLLERS

EXIT
CONVEYOR

FIGURE 11

To clear any jam that may occur in the exit conveyor, first remove the Knife Guard.
Rotate the Conveyor Top Rollers on the exit conveyor to expose the web path.
Remove any jammed or loose material. Replace the Conveyor Top Rollers, making
sure they are down all the way. Replace the Knife Guard.
